Description
Used XYZ UMC 5X 5 Axis VMC. 600 x 600 x 500mm. 120deg + / – A axis 360deg C axis
| SPECIFICATION | |
| Trunnion table size | 600mm diameter |
| X axis traverse | 600mm |
| Y axis traverse | 600mm |
| Z axis traverse | 500mm |
| A axis tilt | +120 deg/-120deg |
| C axis rotation | 360 degree |
| Maximum table load | 600Kg |
| Spindle | BT 40 |
| Maximum spindle speed | 15,000rpm |
| Spindle motor | 22.4kW |
| Maximum spindle torque | 239Nm @ 1100rpm |
| Spindle motor | 35kW |
| Rapid feed rate X,Y,Z axis | 36m/min |
| Rapid feed rate C axis | 540 degrees a second (90 rpm |
| Rapid feed rate A axis | 99 degrees a second (16.6rpm) |
| Toolchanger capacity | 32 tools |
| Approx. weight | 9500kg |
| MACHINE EQUIPPED WITH:- |
| Siemens 840DSL CNC control system with Shop Mill |
| Through spindle coolant, 20 bar |
| Swarf Conveyor |
| Laser toolsetting |
| Traori-this function keeps the tool in an optimised cutting position relative to the workpiece when 5 axis simultaneous machining |
| Networking |
| Lighting |
| Enclosed Guarding |
Click to see the machine >>https://youtu.be/1U2P-k9d_Bs
Price:
£ P.O.A
Details:
- Serial Number : 172822052
- Year : 2018
- Condition : used
Videos:
