Description
PERFECT PFG R500 & R600 Surface Horizontal Spindle Grinders with table diameters of 500mm and 600mm.
Perfect PFG - R Rotary Table Surface Grinder with Horizontal spindle
Specifications |
R500 | R600 |
Travel | ||
Table diameter | 500mm | 600mm |
Max. grinding radius | 310mm | 360mm |
Max. distance from centre of spindle to rotary table | 500mm | |
Rotary table | ||
Rotary table speed | 10~120rpm | |
Spindle motor for rotary table | 3kW | |
Maximum safety table load (magnetic chuck included) |
300kgs | 400kgs |
Weight of magnetic chuck | 152kgs | 228kgs |
Type | Ball bearing (Option: Hydrostatic bearing) | |
Feeding | ||
Rapid power cross feed | 900mm/min | |
Rapid power head elevation | 300mm/min | |
Motor | ||
Spindle motor | 10HP (Option: 15HP) | |
AC Servo motor for vertical feed | 1KW | |
AC Servo motor for cross feed | 0.75kW (biaxial sync) | |
Grinding Wheel | ||
Speed | 1750rpm (60Hz) | |
1450rpm (50Hz) | ||
Dimension: OD x W x ID | 405 x 50 x 127mm | |
Structure | ||
Type | Column type | |
Guideway for vertical | Linear guide way | |
Guide way for cross feed | Linear guide way |
Perfect PFG - R Rotary Table Surface Grinder with Horizontal spindle
Perfect PFG-R Series Rotary Table Surface Grinders with Horizontal spindle
Price:
Details:
- Condition : new
