Specification X Axis traverse 1020mm Y Axis traverse 510mm Z Axis traverse 560mm Table size 1120 x 510mm Spindle speeds 40 – 10000rpm Spindle motor 7.5kW Spindle taper BT 40 Toolchanger capacity 21 tools Machine equipped with Heidenhain 530 CNC Control System 3 off BT 40 toolholders Lighting Enclosed guarding
HARDINGE BRIDGEPORT’S high quality, high performance, highly specified Vertical machining centre, the XR1000 is a rugged and powerful machine developed for tough machining applications, and is well suited to high-speed hard metal cutting. Featuring a 1020 x 610 x 610mm X,Y,Z travels, 12,000rpm #40 spindle and 30 station ATC as standard equipment. Heidenahin and FANUC CNC control options.
QUASER horizontal, vertical and multi-face 5-axis machining centres are increasingly popular due to their superb build quality and suitability for high volume production, tool room and subcontract machining environments. The Quaser ranges of MF vertical machining centres are highly versatile, offering high speed, high powered machining with 4+1 and full 5 axis machining capability along with large X axis machines with a compact footprint.
The HARDINGE BRIDGEPORT GX 1600 is loaded with features and benefits that are unlike any competitive machine tool. Designed for rugged heavy cutting. Heavy duty cast iron base for added stiffness, superior damping characteristics, and added thermal stability. Large pretension and stretched double nut ball screws. Advanced Fanuc i series control with productivity enhancing options.
Superior design characteristics ensure that the HARDINGE BRIDGEPORT GX Series of vertical machining centres with a BT40 taper spindle deliver many years of accurate and reliable machining performance. The GX600 offer 600 x 540 x 540mm travels and the GX1000 has increased X axis travels on 1020mm. Fanuc, Siemens and Heidenhain control options are available.
A 5-axis machining center with second X especially suited for machining of panels and profile-matching. The Mega-Flex is an ideal machine for finishing aluminium profiles with very large sections (profile panels). Due to the large profile section we are also able to finish frames used for mass transportation. The Mega-Flex is a Gantry machine with 5-axis milling motor of 25 KW, 39.5 KW or 44 KW with a tool turret of 36 places.
The QUASER MF vertical machining centres are highly versatile, offering high speed, high powered machining with 4+1 and full 5-axis machining capability along with large X-axis machines with a compact footprint. Superb build quality and stability for high volume production, toolroom and subcontract machining environments.
The Quaser ranges of MF vertical machining centres are highly versatile, offering high speed, high powered machining with 4+1 and full 5 axis machining capability along with large X axis machines with a compact footprint. The MF range offers fast multi-face four + one machining with spindle speeds up to 24,000 rpm with a high efficiency 4/5 axis rotary table.
Offers the highest productivity available from a machine with such a small footprint. Machining capacity and cutting data are also impressive. Axes travels are 1020mm on the X, 610mm on Y and 610mm on Z. Each pallet measures 1050 x 550mm and the maximum workpiece height is 350mm. With the option of the Quaser mill I or a Fanuc 31iB control, the machine is supplied with 20 bar coolant system (with a 50 bar upgrade and chiller option) and a large capacity swarf management system to complement the high capacity machining capabilities of the VMC.
The vertical QUASER MK5U series is designed for max. stability and stiffness. This is ensured by 6 large-size guide shoes in the Y- and Z-axis as well as a strongly ribbed solid cast construction. Standard equipped with a tool magazine for 70 tools (optionally expandable up to 120 tools) as well as a swivel head and an integrated round table with Ø 550 mm.
The MV204 range of vertical machining centres with a 1270 x 700 x 610mm travels offers high speed, high power machining and a rigid cast iron frame with large X & Y travels on a compact footprint. A 2000Kg table load with choices of spindle options including 9,000 and 12,000 belt-drive along with 15,000rpm coupled spindles. Fanuc or Heidenhain CNC control options.
